SOLUTION TEMPERATURE CONTROL VALVE
EVEREST EFI 980197 06/30/04 5-32
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 12-800282 1 CONN, 3/89 X 1/2T BR
2 84192 1 VLV, BALL, 3-WAY, HI-TEMP/PRES INCLUDES REF 3
3 38317 1 HNDL, VALVE, 3-WAY, HI P/T
4 12-800225 2 ELL, 3/8P X 1/2T BR
5 02-000066 2 FLATWASHER, 1/4
6 87162 2 WASHER, 1/4 SPLIT LOCK
7 70017 2 SCR, CAP 1/4-20 X 2.50 HHCS
