Page 54
SIDE PANEL, LEFT
EVEREST EFI 980197 03/09/05
5-8
REF
PART NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 790431 1
BRKT,
WTR
INLET
2 11-800437 1
ADPT,
3/8
BLKHD
3 11-800102 1
NIP,
3/8
HX
BR
4
13-806008
1
DSC, 3/8F X 3/8FP
5 15-808008 1
VLV,
BALL
1/2FP
BS
6
84196
1
VALVE, BALL 1.5 FNPT
7
500694
1
LABEL, VAC/WTR INLET
8 11-800300 1
NIP,
1/2
X
CL
9
790506
1
ADAPTER, HOSE 1/2M X MGT
10 03-000176 1 CLAMP,
HOSE
#16
11
03-000054
2
CLMP, HOSE #32 1.5625/2.5, SST
12
12-800345
1
FTTG, BRB 3/8P X 5/8H BR
13
09-805090
1
HOSE, INT VAC 2.0 X 49.0 BLK
14
12-800269
1
FTTG, BRB 1/2P X 5/8H BR
