AUTOMATIC PUMPOUT-OPTIONAL
EVEREST EFI 980197 11/29/04 5-54
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 00-000210 4 SCR, 1/4-20 X 3/4 SOCHD
2 52-502064 1 CVR, OUTLET WST PMP-OUT
3 00-000312 8 SCR, CAP 1/4 X 1 SOCHD
4 00-000399 1 SCR, CAP 1/4 X 1 3/8 SOC
5 00-000241 8 SCR, CAP 10-32 X 2 SOCHD SS
6 57245 8 NUT, 1/4-20 HEX NYLOCK SS
7 87162 1 WASHER, 1/4 SPLIT LOCK
8 87165 8 WASHER, #10 SPLIT LOCK
9 04-000312 1 RING, RETAIN EXT 1/2
10 04-000334 2 BALL, NYL ID
11 04-000335 2 RING, SNAP 1-7/8D
12 04-000342 1 SPRING, PUMP-OUT BALL PRESS
13 52-502061 1 BDY, INLET WST PMP-OUT
14 16-808241 1 DIAPH, WST TNK PMP-OUT
15 40-902151 1 MOTOR, 1/8HP 12V
16 43-807117 1 GSKT, CVR TOP PMPOUT
17 43-807118 1 GSKT, CVR SD PMPOUT
18 43-810091 1 SEAL, PUMPOUT SHFT
19 43-810100 1 SEAL PUMPOUT CAM
20 43-810101 1 O-RING, 800/1000 .072
21 43-810106 4 O-RING, 1-13/16 ID X 2 OD HDWP
22 45-801927 4 BRG, SHFT PUMP-OUT
23 49-876301 1 VENT, UPR SHFT BRNG HSG
24 50-502025 1 PL, CVR TOP PUMP-OUT
25 50-502026 1 PL, CVR SD PUMP-OUT
26 70094 8 SCR, 1/4-20 X 1/2 SHCS SS
27 11-800504 1 GA, FLOW SIGHT 3/8 NPT
28 52-501828 1 BTM, PLNGR WST TNK PMP-OUT
29 52-501829 1 SHT, 3/4” STROKE WST TNK
30 52-501914 1 RD, CONNECT WST PMP-OUT PART OF 31
31 52-501915 1 GUIDE, PLNGR WST PUMP-OUT INCL. 32, 18, 30
32 52-501921 1 PIN, WRIST PUMP-OUT
33 52-501934 1 TOP, PLNGR PUMP-OUT
34 52-501950 1 BUSH, THREADED
35 52-502062 1 CVR, INLET WST PMP-OUT
36 56-502428 1 BRKT, PMP-OUT SW/CCT BRKR
37 52-501821 1 TOP, WST TNK PUMP-OUT
38 52-501820 1 BASE, WST TANK PMP-OUT
39 52-502063 1 BDY, INLET WST PMP-OUT
