STAIR TOOL-OPTIONAL
EVEREST EFI 980197 06/30/04 5-62
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
- 78519 TL, STAIR, LNG, TM DJ (80015) COMPLETE
- 78521 TL, STAIR, SHT, TM (80015) COMPLETE
1A 56-501715 WAND & HEAD, STAIR TL
1B 56-501907 WAND & HEAD, SHRT STAIR TL
2 52-501576 BODY, WD HDL PORT
3 52-501577 HOLD DOWN, WD HDL PORT
4 04-000053 TIE, CABLE 8” WHT
5A 10-805330 HOSE, 3/16X13-3/4 (1/8PX1/4)
5B 10-805397 HOSE, 3/16X7-1/2 (1/8P X 1/4F)
6 17-803002 TIP, SPRY 9502X1/8P SST
7 00-000282 SCR, CAP 1/4-20 X 1-1/4 SOC
8 12-800060 CONN, 1/4P X 1/4T BR
9 00-000317 SCR, CAP 10-32X1-1/4 SOCH
10 57090 NUT, 10-32 HEX NYLOCK SS
11 61-950496 ASSY, EXTRCTR VLV
12 56015 NIPPLE, 1/4 HEX
13 56012 NIPPLE, 1/4 FPT QD
14 52-501619 TRIGGER, WD VLV
15A 09-805359 SLEEVE, WD HDL 9.5
15B 09-805504 SLEEVE, STAIR TL HDL 7-1/8
16 16-808229 HOLDER, VLV STEM-EXTRCTR VL
17 43-810063 O-RING, .551 ID .691 OD
18 16-808228 SEAT, EXTRCTR VLV
19 16-808189 STEM, EXTRCTR VLV
20 43-810064 BACK-UP, .250DIA
21 43-810062 O-RING, .114 ID .254 OD
22 16-808190 SPRING, EXTRCTR VLV
23 52-501590 BODY, EXTRCTR VLV
- 48-941163 DECAL, STAIR TL NOT SHOWN
- 66-808169 KIT, REP-WD VLV
NOT SHOWN
INCLUDES PARTS 16-19
& 20-22
