1 0 1 0 Funct Reset Display Blank
1 0 1 1 Display Item Tare
1 1 0 0 Peak Valley
1 1 0 1 Meter Reset Display Item
1 1 1 0 Funct Reset Display Item
1 1 1 1 Meter Hold Display Item
0 0 Scale using Scale, Offset
0 1 Scale Coord of 2 Points Method
1 0 Scale using reading Coordinates
0 Peak key action = Peak
1 Peak key action = Tare
0 60 Hz power
1 50 Hz power
09 (U) Setup1 Bit 7 6 5 4 3 2 1 0
0 0 Reset to Net, no dummy zero
0 1 Reset to Net, with dummy zero
1 0 Reset to Gross, no dummy zero
1 1 Reset to Gross, no dummy zero
0D (U) Alarm Confg4 Bit 7 6 5 4 3 2 1 0 Alarm Trigger Delay
60 Hz 50Hz
0 0 0 0.018 s 0.021 s
0 0 1 0.035 0.043
0 1 0 0.07 0.085
0 1 1 0.14 0.17
1 0 0 0.28 0.34
1 0 1 0.56 0.68
1 1 0 1.13 1.36
1 1 1 2.27 2.72
0 0 0 Al3 Band Dev, Al4 Band Dev
0 0 1 Al3 Hysteresis, Al4 Band Dev
0 1 0 Al3 Band Dev, Al4 Hysteresis
0 1 1 Al3 Hysteresis, Al4 Hysteresis
1 0 0 No deviation in menus or calc
0C (U) Alarm Confg3 Bit 7 6 5 4 3 2 1 0
0 0 0 0 Al3 Hi active, Al4 Hi active
0 0 0 1 Al3 Lo active, Al4 Hi active
0 0 1 0 Al3 Disabled, Al4 Hi active
0 1 0 0 Al3 Hi active, Al4 Lo active
0 1 0 1 Al3 Lo active, Al4 Lo active
0 1 1 0 Al3 disabled, Al4 Lo active
1 0 0 0 Al3 Hi active, Al4 disabled
1 0 0 1 Al3 Lo active, Al4 disabled
1 0 1 0 Al3 disabled, Al4 disabled
0 0 Al3 non-latch, Al4 non-latch
0 1 Al3 latch, Al4 non-latch
1 0 Al3 non-latch, Al4 latch
1 1 Al3 latch, Al4 latch
0 0 Relay3 On when Al3 active, Relay4 On when Al4 active
0 1 Relay3 Off when Al3 active, Relay4 On when Al4 active
1 0 Relay3 On when Al3 active, Relay4 Off when Al4 active
1 1 Relay3 Off when Al3 active, Relay4 Off when Al4 active
0B (U) Alarm Confg2 Bit 7 6 5 4 3 2 1 0 Alarm Trigger Delay
60 Hz 50Hz
0 0 0 0.018s 0.021s
0 0 1 0.035 0.043
0 1 0 0.07 0.085
0 1 1 0.14 0.17
1 0 0 0.28 0.34
1 0 1 0.56 0.68
1 1 0 1.13 1.36
1 1 1 2.27 2.72
0 0 0 Al1 Band Dev, Al2 Band Dev
0 0 1 Al1 Hysteresis, Al2 Band Dev
0 1 0 Al1 Band Dev, Al2 Hysteresis
0 1 1 Al1 Hysteresis, Al2 Hysteresis
1 0 0 No deviation in menus or calc
0A (U) Alarm Confg1 Bit 7 6 5 4 3 2 1 0
0 0 0 0 Al1 Hi active, Al2 Hi active
0 0 0 1 Al1 Lo active, Al2 Hi active
0 0 1 0 Al1 Disabled, Al2 Hi active
0 1 0 0 Al1 Hi active, Al2 Lo active
0 1 0 1 Al1 Lo active, Al2 Lo active
0 1 1 0 Al1 disabled, Al2 Lo active
1 0 0 0 Al1 Hi active, Al2 disabled
1 0 0 1 Al1 Lo active, Al2 disabled
1 0 1 0 Al1 disabled, Al2 disabled
0 0 Al1 & Al2 non-latching
0 1 Al1 latching, Al2 non-latching
1 0 Al1 non-latching, Al2 latching
1 1 Al1 & Al2 latching
0 0 Relay1 On when Al1 active, Relay2 On when Al2 active
