FUTEK IPM500 (D500) Digital Display - Manual (Page 44)

1 1 1 0 38:41 46:25
1 1 1 1 1:17:21 1:32:51
0 0 0 300 baud
0 0 1 600 baud
0 1 0 1200 baud
0 1 1 2400 baud
1 0 0 4800 baud
1 0 1 9600 baud
1 1 0 19200 baud
0 Send unfiltered value
1 Send filtered value
2F (L) Filter Bit 7 6 5 4 3 2 1 0
0 0 0 0 Auto Filter
0 0 0 1 Batch (16 samples) filter
Time constant 60 Hz 50 Hz
0 0 1 0 Moving average 0.07s 0.085s
0 0 1 1 Moving average 0.14 0.17
0 1 0 0 Moving average 0.28 0.34
0 1 0 1 Moving average 0.57 0.68
0 1 1 0 Moving average 1.13 1.36
0 1 1 1 Moving average 2.27 2.72
1 0 0 0 Moving average 4.53 5.44
1 0 0 1 Moving average 9.06 10.88
1 0 1 0 No filter (used with Hold)
0 Low adaptive threshold
1 High adaptive threshold
0 Display value of 16-reading batch
1 Display value of filtered signal
0 Take peak of unfiltered signal
1 Take peak of filtered signal
0 Alarm from unfiltered signal
1 Alarm from filtered signal
17 (L) Serial Cnfg3 Bit 7 6 5 4 3 2 1 0
0 0 0 Net + Gross
0 0 1 Net only
0 1 0 Gross only
0 1 1 Peak only (Net or Gross)
1 0 0 Net + Gross + Peak
1 0 1 Valley only
1 1 0 Net + Gross + Peak + Valley
0 or at end of all Items
1 or at end of each Item
(if no Alarm character)
0 Non-latching RTS
1 Latching RTS
0 Normal continuous TX
1 Special Start & Stop characters
0 Full duplex
1 Half duplex
6D (L) Count_ Bit 7 6 5 4 3 2 1 0 Auto-Zero Range
0 0 0 0 0 (no auto-zero)
0 0 0 1 ±1
0 0 1 0 ±2
0 0 1 1 ±3
0 1 0 0 ±4
0 1 0 1 ±5
0 1 1 0 ±6
0 1 1 1 ±7
1 0 0 0 ±8
1 0 0 1 ±9
Count By
0 0 0 1
0 0 1 2
0 1 0 5
0 1 1 10
1 0 0 20
1 0 1 50
1 1 0 100
35 (U) Modbus Addr. 00 to FF Modbus address 0-255
(in Hex format)
2E (U) Setup Bit 7 6 5 4 3 2 1 0 EXT IN A EXT IN B
0 0 0 0 Meter Reset Meter Hold
0 0 0 1 Funct Reset Peak or Valley
0 0 1 0 Meter Hold Peak or Valley
0 0 1 1 Meter Hold Tare
0 1 0 0 Peak or Valley Tare
0 1 0 1 Meter Reset Tare
0 1 1 0 Funct Reset Tare
0 1 1 1 Tare Reset Tare
1 0 0 0 Display Blank Tare
1 0 0 1 Meter Reset Display Blank
Both Ext In A
& Ext In B =
Funct Reset
Funct Reset =
Alarms, Peak,
Valley
44
