FUTEK IPM500 (D500) Digital Display User Manual
Page 29

1 High adaptive threshold
0 Display batch
1 Display filtered signal
0 Take peak of unfiltered signal
1 Take peak of filtered signal
0 Alarm from unfiltered signal
1 Alarm from filtered signal
35 (U)
Modbus Addr. 00 to FF Modbus address 0-255
(in Hex format)
09 (U)
Setup
Bit 7 6 5 4 3 2 1 0 EXT IN A EXT IN B
0 0 0 Reset Meter Hold
0 0 1 Reset Peak Display
* Both ExtinA & * 0 1 0 Meter Hold Peak Display
ExtinB = * 0 1 1 Meter Hold Tare
Function reset * 1 0 0 Peak Display Tare
1 0 1 Tare Reset
1 1 0 External Decimal Point 1
1 1 1 External Decimal Point 2
1 Coordinates of 2 points for Scale, Offset
0 Scale and Offset direct parameters
0 Normal Format, Ser Com Continuous mode
1 Special Start & Stop characters
0 60 Hz power
1 50 Hz power
0 0 4-1/2 digit display (0.1° for temp.)
0 1 Remote display
1 0 4-1/2 digits count by 10 (0.01° for RTD)
1 1 3-1/2 digit display (1° for temp.)
0D (U)
Alarm Confg4
Bit 7 6 5 4 3 2 1 0 Alarm Trigger Delay
60 Hz 50Hz
0 0 0 0.018 s 0.021 s
0 0 1 0.035 0.043
0 1 0 0.07 0.085
0 1 1 0.14 0.17
1 0 0 0.28 0.34
1 0 1 0.56 0.68
1 1 0 1.13 1.36
1 1 1 2.27 2.72
0 0 0 Al3 Band Dev, Al4 Band Dev
0 0 1 Al3 Hysteresis, Al4 Band Dev
0 1 0 Al3 Band Dev, Al4 Hysteresis
0 1 1 Al3 Hysteresis, Al4 Hysteresis
1 0 0 No deviation in menus or calc
0C (U)
Alarm Confg3
Bit 7 6 5 4 3 2 1 0
0 0 0 0 Al3 Hi active, Al4 Hi active
0 0 0 1 Al3 Lo active, Al4 Hi active
0 0 1 0 Al3 Disabled, Al4 Hi active
0 1 0 0 Al3 Hi active, Al4 Lo active
0 1 0 1 Al3 Lo active, Al4 Lo active
0 1 1 0 Al3 disabled, Al4 Lo active
1 0 0 0 Al3 Hi active, Al4 disabled
1 0 0 1 Al3 Lo active, Al4 disabled
1 0 1 0 Al3 disabled, Al4 disabled
0 0 Al3 non-latch, Al4 non-latch
0 1 Al3 latch, Al4 non-latch
1 0 Al3 non-latch, Al4 latch
1 1 Al3 latch, Al4 latch
0 0 Relay3 On when Al3 active, Relay4 On when Al4 active
0 1 Relay3 Off when Al3 active, Relay4 On when Al4 active
1 0 Relay3 On when Al3 active, Relay4 Off when Al4 active
1 1 Relay3 Off when Al3 active, Relay4 Off when Al4 active
0B (U)
Alarm Confg2
Bit 7 6 5 4 3 2 1 0 Alarm Trigger Delay
60 Hz 50Hz
0 0 0 0.018s 0.021s
0 0 1 0.035 0.043
0 1 0 0.07 0.085
0 1 1 0.14 0.17
1 0 0 0.28 0.34
1 0 1 0.56 0.68
1 1 0 1.13 1.36
1 1 1 2.27 2.72
0 0 0 Al1 Band Dev, Al2 Band Dev
0 0 1 Al1 Hysteresis, Al2 Band Dev
0 1 0 Al1 Band Dev, Al2 Hysteresis
0 1 1 Al1 Hysteresis, Al2 Hysteresis
1 0 0 No deviation in menus or calc
0A (U)
Alarm Confg1
Bit 7 6 5 4 3 2 1 0
0 0 0 0 Al1 Hi active, Al2 Hi active
0 0 0 1 Al1 Lo active, Al2 Hi active
0 0 1 0 Al1 Disabled, Al2 Hi active
29
