0 Normal continuous TX
1 Special Start & Stop characters
0 Full duplex
1 Half duplex
35 (L) Decimal Point 01 Byte values in hex XXXXX.
02 (2 hex characters/byte) XXXX.X
03 XXX.XX
04 XX.XXX
05 X.XXXX
06 .XXXXX
34 (L) Lockout2
0 = unlocked
1 = locked
Bit 7 6 5 4 3 2 1 0 Menu item & front panel lockout
1 Serial configuration
1 Analog output scaling
1 Alarm setpoint programming
1 Alarm setup
1 Front panel DPM reset
1 Front panel Peak & Alarm reset
1 View alarm setpoints
1 View Peak value & Tare function
33 (L) Lockout1
0 = unlocked
1 = locked
Bit 7 6 5 4 3 2 1 0 Menu item & front panel lockout
1 Offset, Lo & Hi readings
1 Scale, Lo In, Hi In
1 Filter Setup
1 Setup, Config & Decimal Point
1 InPut Menu Item
32 (L) Serial Cnfg2 Bit 7 6 5 4 3 2 1 0
X X X X X Binary Custom ASCII addr. 0-31
0 Continuous mode
1 Command mode
0 Alarm data not included with rdg.
1 Alarm data included with rdg.
0 No following )
1 following
31 (L) Serial Cnfg1 Bit 7 6 5 4 3 2 1 0 Continuous Output Data Rate
60 Hz 50 Hz
0 0 0 0 0.017s 0.02s
0 0 0 1 0.28 0.34
0 0 1 0 0.57 0.68
0 0 1 1 1.1 1.4
0 1 0 0 2.3 2.7
0 1 0 1 4.5 5.4
0 1 1 0 9.1 10.9
0 1 1 1 18.1 21.8
1 0 0 0 36.3 43.5
1 0 0 1 1:13 1:27
1 0 1 0 2:25 2:54
1 0 1 1 4:50 5:48
1 1 0 0 9:40 11:36
1 1 0 1 19:20 23:13
1 1 1 0 38:41 46:25
1 1 1 1 1:17:21 1:32:51
0 0 0 300 baud
0 0 1 600 baud
0 1 0 1200 baud
0 1 1 2400 baud
1 0 0 4800 baud
1 0 1 9600 baud
1 1 0 19200 baud
0 Send unfiltered value
1 Send filtered value
2F (L) Filter Bit 7 6 5 4 3 2 1 0
0 0 0 0 Auto Filter
0 0 0 1 Batch (16 samples) filter
Time constant 60 Hz 50 Hz
0 0 1 0 Moving average 0.07 s 0.085 s
0 0 1 1 Moving average 0.14 0.17
0 1 0 0 Moving average 0.28 0.34
0 1 0 1 Moving average 0.57 0.68
0 1 1 0 Moving average 1.13 1.36
0 1 1 1 Moving average 2.27 2.72
1 0 0 0 Moving average 4.53 5.44
1 0 0 1 Moving average 9.06 10.88
1 0 1 0 Unfiltered
0 Low adaptive threshold
27
