2. INTRODUCTION, CUSTOM ASCII SERIAL PROTOCOL

This manual applies to our programmable digital panel meters, counters

and timers with Series 2

firmware. Before applying this manual to your device, verify that the label states

"Series 2."

The Custom ASCII Protocol, which is the subject of this manual, is a simple serial commu-

nications protocol which is optimized for use with Series 2 programmable digital panel meters,

counters

and timers. It is compatible with RS232 and RS485 signals. It supports point-to-point

and multipoint (or multidrop) communications, with addressing of up to 31 devices

on the same

RS485 serial data line.
Digital panel meters, counters and timers require a plug-in option board for serial communi-
cations. This can be an RS232 board, RS485 board, or RS585 Modbus board. The RS485 and

RS485 Modbus boards are electrically equivalent, but the RS485 board uses RJ11 connectors,

while the RS485 Modbus board uses RJ45 connectors. The two RJ11 or RJ45 connectors are

wired in parallel to allow daisy chaining with no need for a hub. One of the jacks is equipped with
two indicator LEDs.
The Modbus Protocol is a software-selectable alternative to the Custom ASCII Protocol and can

be used with RS232 or RS485 signal levels. It is an industry standard which allows devices by

different manufacturers to be digitally addressed on the same RS485 serial data line. However, it
is substantially more complex than the Custom ASCII Protocol. For additional information, please

refer to the separate Modbus Protocol Communications Manual.

3. JUMPER SETTINGS & FIELD WIRING FOR SERIAL COMMUNICATIONS

3.1 SAFETY WARNINGS
Digital panel meters, counters, timers and transmitters may be powered with AC (mains) from

95-240V ac ±10% or 95-300V dc with the high voltage power supply option, or 10-34V ac ±10%

or 10-48 Vdc with the low voltage power supply option. To avoid the possibility of electrical shock

or damaging short circuits, always unplug the device before opening the case. Please refer to the

respective device manuals for full safety information and instruction on how to open the case.

Signal wiring changes external to the case can be made safely while the units are under power.

3.2 CONNECTION OF METERS, COUNTERS & TIMERS TO COMPUTER

3
