0A
09
08
07
06
05
04
03
02
01
00
High Reading 1
High Input 2
Low Reading 3
Low Reading 1
Low Input 2
Offset 3
Offset 1
Scale Factor 2
Setpoint2 3
Setpoint2 1
Setpoint1 2
High Input 3
High Input 1
Low Reading 2
Low Input 3
Low Input 1
Offset 2
Scale Factor 3
Scale Factor 1
Setpoint2 2
Setpoint1 3
Setpoint1 1
10. APPENDIX B: COUNTER / TIMER MEMORY ADDRESSES
AND DATA DEFINITIONS
10.1 COUNTER / TIMER 1-BYTE RAM MEMORY DATA
(L) = Lower memory, (U) = Upper memory
Hex Address Item Name Bit Assignment
43 Resolution Bit 7 6 5 4 3 2 1 0 Multiplier
0 0.00001
1 0.0001
1 0 0.001
1 1 0.01
1 0 0 0.1
1 0 1 1
1 1 0 10
1 1 1 100
1 0 0 0 1000
1 0 0 1 10000
1 0 1 0 100000
42 Recog. Char. ASCII value of custom recognition character
41 Slope Bit 7 6 5 4 3 2 1 0
0 Positive slope Channel B
1 Negative slope Channel B
0 Positive slope Channel A
1 Negative slope Channel A
3E Scale
Multiplier
Bits 3-0 = 0-A SCALE1 multiplier
Bits 7-4 = 0-A SCALE2 multiplier
0-A: Same multiplier as for Resolution
3D Analog Setup Bit 7 6 5 4 3 2 1 0 Analog Output Source
0 0 Filtered Item
0 1 Item 1
1 0 Item 2
1 1 Item 3
0 Current output
1 Analog voltage output
3C Source Bit 7 6 5 4 3 2 1 0
Compare Setpoint 2 to:
0 0 Filtered Item
