Rev 5

MN890570

5 of 30

SAFETY PRECAUTIONS

Step Four

About  this  Manual:    PLEASE  READ  THE  ENTIRE  QUICK  START  PRIOR  TO  INSTALLING  OR  USING  THIS

PRODUCT.    This  manual  includes  information  on  the  Series  ULS  Ultrasonic  Level  Switch,  controller  and
transmitter from Dwyer Instruments, Inc. Please refer to the part number located on the switch label to verify
the exact model configuration, which you have purchased.

User’s  Responsibility  for  Safety:    Dwyer  Instruments,  Inc  manufactures  a  broad  range  of  level  sensing

technologies. While each of these sensors is designed to operate in a wide variety of applications, it is the user’s
responsibility to select a sensor model that is appropriate for the application, install it properly, perform tests of
the  installed  system,  and  maintain  all  components.  The  failure  to  do  so  could  result  in  property  damage  or
serious injury.

Proper Installation and Handling:  Only professional staff should install and/or repair this product.  Install

the transmitter with the included FKM gasket and never over tighten the transmitter within the fitting.  Always
check for leaks prior to system start‐up.

Wiring and Electrical:  A supply voltage of 12 to 28 VDC is used to power the Series ULS.  Electrical wiring of the

transmitter should be performed in accordance with all applicable national, state, and local codes.  Note: Series
ULS uses latching relays.  When power is removed to the sensor, the relays will remain in their last state.  Ex: If the
relay is energized, when power is removed, the relay will remain in an energized state.


Material  Compatibility:    The  enclosure  is  made  of  Polycarbonate  (PC).    The  transducer  is  made  of

Polyvinylidene Fluoride (PVDF).  Make sure that the model, which you have selected, is chemically compatible
with the application media.

Enclosure:    While  the  transmitter  housing  is  liquid‐resistant  the  Series  ULS  is  not  designed  to  be

operational when immersed.  It should be mounted in such a way that the enclosure and transducer do not
come into contact with the application media under normal operational conditions.

Safety

Installation should be done by properly trained staff

Supply voltage should never exceed a maximum of 28 VDC

Make sure the sensor is chemically compatible with your application

Design a fail‐safe system that accommodates the possibility of sensor and/or power failure

This sensor should not be used in classified hazardous environments

Make  a  Fail‐Safe  System:    Design  a  fail‐safe  system  that  accommodates  the  possibility  of  transmitter

and/or power failure.  Dwyer Instruments, Inc recommends the use of redundant backup systems and alarms
in addition to the primary system.

Flammable, Explosive or Hazardous Applications:  Series ULS should not be used within classified

hazardous environments.

Warning: Always use the FKM gasket when installing the Series ULS, and make sure that all electrical

wiring of the switch is in accordance with applicable codes.
