KS 90-1 / KS 92-1
57
Parameters
PAr.2
Name
Value range Description
Default
Pb12
1...9999 1
Proportional band 1 (heating) in phys. dimensions (e.g. °C),
2. parameter set
100
Pb22
1...9999 1
Proportional band 2 (cooling) in phys. dimensions (e.g. °C),
2. parameter set
100
Ti22
0,1...9999
Integral action time 2 (cooling) [s], 2. parameter set
10
Ti12
0,1...9999
Integral action time 1 (heating) [s], 2. parameter set
10
Td12
0,1...9999
Derivative action time 1 (heating) [s], 2. parameter set
10
Td22
0,1...9999
Derivative action time 2 (cooling) [s], 2. parameter set
10
SEtP
Name
Value range Description
Default
SP.LO
-1999...9999
Set-point limit low for Weff
0
SP.Hi
-1999...9999
Set-point limit high for Weff
900
SP.2
-1999...9999
Set-point 2.
0
r.SP
0...9999
Set-point gradient [/min]
OFF
SP
-1999...9999
Set-point (only visible with BlueControl!)
0
g
SP.LO and SP.Hi should be within the limits of rnGH and rnGL see
configuration r Controller page
InP.1
Name
Value range Description
Default
InL.1
-1999...9999
Input value for the lower scaling point
0
OuL.1
-1999...9999
Displayed value for the lower scaling point
0
InH.1
-1999...9999
Input value for the upper scaling point
20
OuH.1
-1999...9999
Displayed value for the lower scaling point
20
t.F1
0,0...9999
Filter time constant [s]
0,5
Etc.1
0...100 (°C)
32...212 (°F)
External cold-junction reference temperature (external TC)
OFF
InP.2
Name
Value range Description
Default
InL.2
-1999...9999
Input value for the lower scaling point
0
OuL.2
-1999...9999
Displayed value for the lower scaling point
0
InH.2
-1999...9999
Input value for the upper scaling point
50
OuH.2
-1999...9999
Displayed value for the upper scaling point
50
t.F2
0,0...9999
Filter time constant [s]
0,5
InP.3
Name
Value range Description
Default
InL.3
-1999...9999
Input value for the lower scaling point
0
OuL.3
-1999...9999
Displayed value for the lower scaling point
0
InH.3
-1999...9999
Input value for the upper scaling point
20
OuH.3
-1999...9999
Displayed value for the upper scaling point
20
