Configuration level
KS 90-1 / KS 92-1 33 Configuration parameters
Name Value range Description Default
6 no controller input (e.g. transmitter input instead)
7 Process value x1
S.tYP Sensor type selection 30
30 0...20mA / 4...20mA 1
31 0...50mA AC 1
50 Potentiometer ( 0...160 Ohm) 1
51 Potentiometer ( 0...450 Ohm) 1
52 Potentiometer ( 0...1600 Ohm) 1
53 Potentiometer ( 0...4500 Ohm) 1
Corr Measured value correction / scaling 0
0 Without scaling
1 Offset correction (at CAL level)
(offset entry is at controller CALlevel)
2 2-point correction (at CALlevel)
(calibration is at controller CALlevel)
3 Scaling (at PArA level)
In.F -1999...9999 Alternative value for error at INP2
If a value is adjusted, this value is used for display and calculation
in case of error (e.g. FAIL).
a Before activating a substitute value, the effect in the
control loop should be considered!
OFF
fAI2 Forcing INP2 (only visible with BlueControl!) 0
0 No forcing
1 Forcing via serial interface
1 with current and voltage input signals, scaling is required (see chapter 5.3)
InP.3
Name Value range Description Default
I.Fnc Function selection of INP3 1
0 no function (subsequent input data are skipped)
1 heating current input
2 External set-point SP.E (switch-over -> LOGI/ SP.E)
3 Yp input
4 Second process value X2
5 External positioning value Y.E
(switch-over r LOGI / Y.E)
6 no controller input (e.g. transmitter input instead)
7 Process value x1
S.Lin
Linearization
(only at S.tYP = 30 (0..20mA) and 40 (0..10V) adjustable)
0
0 none
1 Linearization to specification. Creation of linearization table with
BlueControl (engineering tool) possible. The characteristic for
KTY 11-6 temperature sensors is preset.
S.tYP
Sensor type selection 30
0 thermocouple type L (-100...900°C) , Fe-CuNi DIN
1 thermocouple type J (-100...1200°C) , Fe-CuNi
