Configuration level
Configuration parameters 32 KS 90-1 / KS 92-1
Name Value range Description Default
20 Pt100 (-200.0 ... 100,0 °C)
( -200,0 ... 150,0°C with reduced lead resistance: measuring
resistance + lead resistance ß160 [ )
21 Pt100 (-200.0 ... 850,0 °C)
22 Pt1000 (-200.0 ... 850.0 °C)
23 special 0...4500 Ohm (preset to KTY11-6)
24 special 0...450 Ohm
30 0...20mA / 4...20mA 1
40 0...10V / 2...10V 1
41 special -2,5...115 mV 1
42 special -25...1150 mV 1
50 potentiometer 0...160 Ohm 1
51 potentiometer 0...450 Ohm 1
52 potentiometer 0...1600 Ohm 1
53 potentiometer 0...4500 Ohm 1
S.Lin
Linearization (only at S.tYP= 23 (KTY 11-6), 24 (0...450 ), 30
(0..20mA), 40 (0..10V), 41 (0...100mV) and 42 (special -25...1150 mV))
0
0 none
1 Linearization to specification. Creation of linearization table with
BlueControl (engineering tool) possible. The characteristic for
KTY 11-6 temperature sensors is preset.
Corr Measured value correction / scaling 0
0 Without scaling
1 Offset correction (at CAL level)
(controller offset adjustment is at CALlevel)
2 2-point correction (at CAL level)
(calibration is at the controller CALlevel)
3 Scaling (at PArA level)
4 Autom. calibration (only with positionfeedback Yp)
In.f -1999...9999 Alternative value for error at INP1
If a value is adjusted, this value is used for display and calculation
in case of error (e.g. FAIL).
a Before activating a substitute value, the effect in the
control loop should be considered!
OFF
fAI1 Forcing INP1 (only visible with BlueControl!) 0
0 No forcing
1 Forcing via serial interface
1 with current and voltage input signals, scaling is required (see chapter 5.3)
InP.2
Name Value range Description Default
I.Fnc
Function selection of INP2 1
0 no function (subsequent input data are skipped)
1 heating current input
2 external set-point (SP.E)
3 Yp input
4 Second process value X2
5 External positioning value Y.E
(switch-over r LOGI / Y.E)
