Configuration level
KS 90-1 / KS 92-1 37 Configuration parameters
Name Value range Description Default
O.Act Method of operation of output OUT3 (only visible when O.TYP=0) 1
0 direct / normally open
1 inverse / normally closed
Out.0 -1999...9999 Scaling of the analog output for 0% (0/4mA or 0/2V, only visible
when O.TYP=1..5)
0
Out.1
-1999...9999 Scaling of the analog output for 100% (20mA or 10V, only visible
when O.TYP=1..5)
100
O.Src Signal source of the analog output OUT3 (only visible when
O.TYP=1..5)
1
0 not used
1 controller output y1 (continuous)
2 controller output y2 (continuous)
3 process value
4 effective set-point Weff
5 control deviation xw (process value - set-point)
6 measured value position feedback Yp
7 measured value INP1
8 measured value INP2
9 measured value INP3
O.FAI
Failbehaviour, behaviour of the analog output, if the signal source
(O.Src) is disturbed.
0
0 upscale
1 downscale
Y.1
Y.2
Controller output Y1/Y2 (only visible when O.TYP=0) 0
0 not active
1 active
Lim.1
Lim.2
Lim.3
Limit 1/2/3 signal (only visible when O.TYP=0) 1
0 not active
1 active
dAc.A
Valve monitoring (DAC) (only visible when O.TYP=0) 0
0 not active
1 active
LP.AL
Interruption alarm signal (LOOP) (only visible when O.TYP=0)
(Loop-Alarm)
0
0 not active
1 active
HC.AL Heating current alarm signal (only visible when O.TYP=0) 0
0 not active
1 active
HC.SC Solidstaterelay(SSR)shortcircuitsignal(onlyvisiblewhenO.TYP=0) 0
0 not active
1 active
FAi.1
FAi.2
FAi.3
INP1/ INP2 / INP3 error (only visible when O.TYP=0) 1
0 not active
1 active
dP.Er PROFIBUS error 0
0 not active
1 active: Profibus trouble, no communication with this instrument.
