Configuration level
Configuration parameters 40 KS 90-1 / KS 92-1
Name Value range Description Default
I.Chg Switching of the actual process value between Inp1 and X2 0
0 no function (switch-over via interface is possible)
2 DI1 switches
3 DI2 switches (only visible with OPTION)
4 DI3 switches (only visible with OPTION)
5 è - key switches
di.Fn
Function of digital inputs (valid for all inputs) 0
0 direct
1 inverse
2 toggle key function
fDI1
fDI2
fDI3
Forcing di1/2/3 (only visible with BlueControl!) 0
0 No forcing
1 Forcing via serial interface
othr
Name Value range Description Default
bAud
Baudrate of the interface (only visible with OPTION) 2
0 2400 Baud
1 4800 Baud
2 9600 Baud
3 19200 Baud
Addr 1...247 Address on the interace (only visible with OPTION) 1
PrtY Data parity on the interface (only visible with OPTION) 1
0 no parity (2 stop bits)
1 even parity
2 odd parity
3 no parity (1 stopbit)
dELY
0...200 Delay of response signal [ms] (only visible with OPTION) 0
dP.AD 0...126 Profibus address 126
bc.up Behaviour as backup controller (see page ) 0
0 No backup functionality
1 With backup functionality
O2 Entering parameter for O
2
in ppm or % 0
0 Parameter for O
2
-function in ppm
1 Parameter for O
2
-function in %
Unit Unit 1
0 without unit
1 °C
2 °F
dP Decimal point (max. number of digits behind the decimal point) 0
0 no digit behind the decimal point
1 1 digit behind the decimal point
2 2 digits behind the decimal point
3 3 digits behind the decimal point
