Configuration level
KS 90-1 / KS 92-1
41
Configuration parameters
Name Value range Description
Default
LED
Function allocation of status LEDs 1 / 2 / 3 / 4
0
10
OUT1, OUT2, OUT3, OUT4
11
Heating, alarm 1, alarm 2, alarm 3
12
Heating, cooling, alarm 1, alarm 2
13
Cooling, heating, alarm 1, alarm 2
14
Bus error
dISP
0...10
Display luminosity
5
C.dEl
0..200
Modem delay [ms]
Additional delay time, before the received message is evaluated in
the Modbus. This time is required, unless messages are transferred
continuously during modem transmission.
0
FrEq
Switching 50 Hz / 60 Hz (only visible with BlueControl!)
0
0
50 Hz
1
60 Hz
MAst
Modbus master/slave (see page ) (visible only with BlueControl
®
)
0
0
No
1
Yes
CycL
0...240
Master cycle (sec.) (see page ) (visible only with BlueControl
®
!)
120
AdrO
-32768...3276
7
Destination address (see page ) (visible only with BlueControl
®
!)
1100
AdrU
-32768...3276
7
Source address (see page ) (visible only with BlueControl
®
!)
1100
Numb
0...100
Number of data (see page ) (visible only with BlueControl
®
!)
1
ICof
Block controller off (only visible with BlueControl!)
0
0
Released
1
Blocked
IAda
Block auto tuning (only visible with BlueControl!)
0
0
Released
1
Blocked
IExo
Block extended operating level (only visible with BlueControl!)
0
0
Released
1
Blocked
ILat
Suppression error storage (visible only with BlueControl
®
!)
0
0
No: error message remain in the error list until
acknowledgement.
1
Yes alarms are deleted from the error list as soon as
corrected
Pass
OFF...9999
Password (only visible with BlueControl!)
OFF
IPar
Block parameter level (only visible with BlueControl!)
0
0
Released
1
Blocked
ICnf
Block configuration level (only visible with BlueControl!)
0
0
Released
1
Block
ICal
Block calibration level (only visible with BlueControl!)
0
0
Released
1
Blocked
