Press
È to
Start (time) and
Æ to position the cursor under the time column
HH/MM/SS (24 hour
clock in Hours/minutes/seconds, eg: 23:02:16 ) and then
È or Ç to set the logging start Time. Press
Æ to return to
Start .
Press
È to Interval and Æ to the
Sec/Min column. Press
È or Ç to set the logging time interval.
Choose:
30 Sec
10 Sec
5 Sec
2 Sec
1 Sec
30 Min
10 Min
5 Min
2 Min
1 Min
Press
Æ to return to to
Interval and
È to
Reset Log? To erase all existing data in the log press
Æ
to Yes and
È. To keep existing data in the Log press È from
Reset Log? If you have made changes
to the Start Date, Time or Interval, the data logger will automatically start a new “session”. The Ultrason
will display “
xxxxx Hrs/Days Left ”.
From the xxxxx Hrs Left display press
È to
Store? Yes . Press
Æ to
Yes and then
È to save your
Data Logging setup, or press
È from
Store? to cancel changes made above and exit without storing
changes.
From the Data Logging Store? Yes prompt the menu will return to RUN STOP SETUP . Press
Æ to
position the cursor under RUN and press
È to activate the Data Logger to start at your selected start Date
and Time. The Ultrason will display SESSION NO. x . Press
È to return to
DATA LOGGING .
‘Event’ based Trend Logging
Event based logging stores data points only when a High or Low flow set point has been reached.
With cursor under Event press
È to
HiAlm LoAlm . HiAlm will log points above a selectable flow
rate, while LoAlm will log points below a selectable flow rate. Position the cursor under HiAlm or
LoAlm and press
È to the
At: prompt. Press
Æ to the numerals column and press È or Ç to set flow
alarm logging set point. Press
Æ to return to
At:
