GDM-8246 MULTIMETER

PROGRAMMER MANUAL

⎯ 26 ⎯

Examples:

:CONFigure:RANGe? might return 50.000 to indicate the 50V range at
DCV.

Please refer to the representative unit for every function range as follows:

Table 6-1:

Voltage V

Capacitance

nF

Current mA Diode V

Resistance kohm Continuity kohm

Frequency kHz

dBm

dBm

:CONFigure:MODe?(query only)

Function:

Return the total value of the selected calculation mode.

Syntax:

:CONFigure:MODe?

Returns:

is in the range from 0 through 255.

Examples:

:CONFigure:MODe? might return 1 to indicate the MIN mode to be
slected.

Please refer to the representative total value for every attached
calculation mode as follows:

GDM-8246 MULTIMETER

PROGRAMMER MANUAL

⎯ 27 ⎯

Table 6-2:

Calculation Function

Corresponding Value

MIN 1

MAX 2

HOLD 4

AUTOHOLD 8

dBm 16
REL 32

COMP 64


:CONFigure:FUNCtion?(query only)

Function:

Return the present selected function.

Syntax:

:CONFigure:FUNCtion?

Returns:

String

Examples:

:CONFigure:FUNCtion? might return “DCV” to indicate the present DC
voltage function.

Please refer to the returned message for every function as follows:

Table 6-3:

Function Description

DC Voltage

DCV

AC Voltage

ACV

AC+DC Voltage

AC+DCV

ACV + Frequency

Hz+ACV
