Edwards Signaling 102 DeviceNet - Manual (Page 3)

P/N 3100125 ISSUE 3 PAGE 3
For Units Configured with 3 Light Modules
BYTE BIT7 BIT6 BIT5 BIT4 BIT3 BIT2 BIT1 BIT0
0 PWR FAIL DON'T DON'T DON'T DON'T LMP 3 LMP 2 LMP 1
1=PWR LOST CARE CARE CARE CARE 1 = REP 1 = REP 1 = REP
2=PWR OK 0 = OK 0 = OK 0 = OK
1 DON'T DON'T DON'T DON'T DON'T LMP 3 LMP 2 LMP 1
CARE CARE CARE CARE CARE 1 = ON 1 = ON 1 = ON
0 = OFF 0 = OFF 0 = OFF
2 DON'T DON'T DON'T DON'T Sounder Tone Tone Tone
CARE CARE CARE CARE 1 = ON MSB LSB
0 = OFF
For Units Configured with 2 Light Modules
BYTE BIT7 BIT6 BIT5 BIT4 BIT3 BIT2 BIT1 BIT0
0 PWR FAIL DON'T DON'T DON'T DON'T DON'T LMP 2 LMP 1
1=PWR LOST CARE CARE CARE CARE CARE 1 = REP 1 = REP
2=PWR OK 0 = OK 0 = OK
1 DON'T DON'T DON'T DON'T DON'T DON'T LMP 2 LMP 1
CARE CARE CARE CARE CARE CARE 1 = ON 1 = ON
0 = OFF 0 = OFF
2 DON'T DON'T DON'T DON'T Sounder Tone Tone Tone
CARE CARE CARE CARE 1 = ON MSB LSB
0 = OFF
For Units Configured with 1 Light Module
BYTE BIT7 BIT6 BIT5 BIT4 BIT3 BIT2 BIT1 BIT0
0 PWR FAIL DON'T DON'T DON'T DON'T DON'T DON'T LMP 1
1=PWR LOST CARE CARE CARE CARE CARE CARE 1 = REP
2=PWR OK 0 = OK
1 DON'T DON'T DON'T DON'T DON'T DON'T DON'T LMP 1
CARE CARE CARE CARE CARE CARE CARE 1 = ON
0 = OFF
2 DON'T DON'T DON'T DON'T Sounder Tone Tone Tone
CARE CARE CARE CARE 1 = ON MSB LSB
0 = OFF
