P/N 3100125 ISSUE 3 PAGE 15
Electrical Manufacturers Replacement Lamp Life (hours)
Catalog No. Ratings Lamp Ratings Lamp Calculated # Projected ##
Base Units
102TBS-DN-G1
24V DC, 1.75A + N/A N/A N/A N/A
102TBS-DN-N5 120V AC, 0.60A +
Optional Horn Assembly
102SIGMT-DN-G1
24V DC, 0.05A N/A N/A N/A N/A
Lens Modules
102LM-*
N/A N/A N/A N/A N/A
Light Sources
102LS-SINH-G1
24V DC, 0.32A 9 Watts 50LMP-9WH 12,000 --
or Ind. Trade 303*** 3,000 --
102LS-SINH-N5 120V AC, 0.11A 12 Watts 50LMP-12WH 20,000 --
102LS-SIN-G1 24V DC, 0.32A 10 Watts 50LMP-10W or 10,000 --
Ind. Trade 303 3,000 --
102LS-SIN-N5 120V AC, 0.08A 10 Watts 50LMP-10W 2,500 --
102LS-ST-G1 24V DC, 0.30A 3 Joule Strobe -- 3,000 ### --
102LS-ST-N5 120V AC, 0.12A 3 Joule Strobe -- 3,000 ### --
102LS-SLEDA-G1** 24V DC, 0.062A -- N/A 100,000 --
102LS-SLEDB-G1**
102LS-SLEDG-G1**
102LS-SLEDR-G1**
102LS-SLEDW-G1**
102LS-SLEDA-N5**
120V AC, 0.022A -- N/A 100,000 --
102LS-SLEDB-N5**
102LS-SLEDG-N5**
102LS-SLEDR-N5**
102LS-SLEDW-N5**
+ Currents shown are for a stackable indicator with 5 light modules.
*Signifies lens module color (A - amber, B - blue, C - clear, G - green, R - red)
**Signifies lens and LED module color (A - amber, B - blue, G - green, R - red) NOTE: LED light sources must be used with
the corresponding color lens module (e.g., a blue LED light source, 102LS-SLEDB-G1, must be used with a blue lens,
102LM-B).
***A non-halogen lamp, as listed, may be used in place of the halogen lamp.
# At nominal operating voltage.
## Projected lamp life based on manufacturer's calculated lamp life @ 65 fpm and 50% duty cycle.
### Strobe tube life @ operating power to 75% efficiency.
Table 1. Triliptical DeviceNet Status Indicator Specifications
Operating DeviceNet Bus Current 0.12A
Current Draw supplied by separate power supply (per Light Module) DC: 0.062 to 0.320A
AC: 0.022 to 0.120A
In-Rush Current supplied by separate power supply (per Light Module) DC: 1.2A
AC: 0.5A
Flash Rate (selectable via second data byte of POLL command) 45, 60 or 80 fpm
Operating Temperature 32F to 158F (0C to 70C)
Table 2. Pertinent DeviceNet Specifications
