SEED HAWK ® 2014 AIRCART OPERATOR’S MANUAL SEED HAWK ® 2014 AIRCART OPERATOR’S MANUAL 44
1. Press the Power button to begin.
2. As the Seed Hawk Logo is dis-
played, the monitor performs a self-
test. During this self test, the monitor
will check that all learned sensors are
connected.
3. Once this test is complete, all sen-
sors found by the system are listed as
shown in the image.
4. Press the soft key labeled “OK” to
continue to the Normal Operate
Screen.
NOTE: For everyday op-
eration, the monitor will
remember all settings that
have been saved from the
previous use.
Activate Clutch Key: This key is used to engage or disengage the clutch.
(Reminder: Clutch Status is indicated in the Top Section of the Display).
Meter Rate Screen: Pressing this button brings up a screen which allows
adjusting meter application rates and turning meters on and off.
Soft Keys: These keys represent settings menus. They displayed option on a
soft key may be different depending on the menu the operator has chosen. The
User pushes these key to make the displayed selection
7.2 Normal Start up
45
7.2.1 Normal Operating Screen
Ground
Speed
Drive Status Bin Level
User Selectable Display Window Area
Alarm Status
NOTE: The User Selectable
Display Window Area is
“Sensor Selectable” as well
as “View Selectable”. This is
explained in detail in Section
7.2.4 and Section 7.2.5.
Bin Level Status: The levels of up to 4 bin sensors are shown in the left most
area.
Active Alarm: Any time an alarm is active a bell will appear to the right of the
4th Bin Level Icon.
Drive Status: The gear icon is an outline when the drive is disengaged and a
solid icon when the drive is engaged.
Ground Speed: Indicated by miles per hour (km/hr) in the top right corner
7.3 Soft Key Menus
NOTE: The Soft Key Menus
are timed operations. If
too long of a period passes
without a keyed entry, the
monitor will revert back to
its Normal Operate Screen
display mode and changes
will not be made.
From the Main Operating
Screen, Press any
Soft Key
to activate the Soft Key
Menu.
