Operation • 23
English
7. OPERATION
7.1 Operating concept
Swiveling the touchscreen display The touchscreen display of the device can be swiveled. As a result, it can
be optimally positioned for every application.
♦ Swivel the touchscreen display for comfortable operation and reading.
ATTENTION!
Damage to device
The swivel mechanism of the touchscreen display has an end stop.
Do not attempt to swivel the touchscreen display by more than
180°. This leads to mechanical damage to the housing and the
internal cabling.
− In every direction, only rotate the touchscreen display as far as
the end stop.
Switching on the device The device is switched on using the ON/OFF button. During the switch-on
procedure, the device performs a self-test. The self-test may take several
seconds.
1. Give the ON/OFF button a brief press.
The LED of the button turns white.
The internal PC of the device boots up. This takes several seconds.
The weighing function is available if the LED of the button turns white
continuously and the
weight/height tab is shown in the display.
2. In the display, press the bia tab.
The bioelectric impedance analysis function is available if the
message
self-test running is no longer displayed and the dialog
window module selection appears.
The device is ready for operation.
Selecting functions Functions can be selected using the following elements of the touchscreen
display:
• Tab
• Buttons
• Drop-down menus
• Checkboxes
♦ In order to select a function, press directly on the corresponding
display element (here: tab, button).
max. 180°!
max. 180°!
