Connecting power from breaker to a heat stage, Using the scs™ panel – Hired-Hand Farm Hand Series: SCS w/Back-Up User Manual
Page 21
Part No. 4801-5117 Rev. 8-01
Farm Hand SCS
19
17.8 Connecting Power from Breaker to a Heat Stage or Cool Stage
All wiring must meet
N.E.C. and all Local Standards.
Connecting Power from Breaker to a Heat Stage
Breaker Panel
Stage Load
Heater
120V/240V
IN
Stage 1 Stage
2
Stage 3 Stage 4
Stage 5 Stage6
Stage 7 Stage 8
HOT
120V NEUT
240V NEUT
GROUND
SCS Panel
120V/240V
120/240
VAC Hot
120/240
VAC Neutral
Ground
Note: When using a single pole
contactor,
only line 2 of the 120 Volt supply to the stage
is broken by the
contactor.
Using the SCS™ Panel
120/240
VAC Line 1
120/240
VAC Line 2
Ground
120/240
VAC Line 1
120/240
VAC Line 2
Ground
120/240
VAC Line 1
120/240
VAC Line 2
Ground
NOTE
NOTE
Stage Load
Fan
120V/240V
