Hired-Hand Farm Hand Series: SCS w/Back-Up User Manual
Page 15
Part No. 4801-5117 Rev. 8-01
Farm Hand SCS
13
17.2 Setting the Back-Up Board Jumpers, Sensors and Alarm Connections
Inset A
Inset B
Inset C
Inset A
Jumper Connection to
Enable Sensor 2
Inset B
Sensor 1 & 2 Connections
Inset C
Back-Up Alarm Connection
Sensor 2
Enabled
Installed – Enabled
Vacant – Disabled
Jumper
