Hired-Hand Farm Hand Series: SCS w/Back-Up - Manual (Page 19)

Part No. 4801-5117 Rev. 8-01 Farm Hand SCS 17
17.6 SCS™ Connections to the Power Supply
H
O
T 12
0V N
E
UT 24
0V N
E
UT
G
R
O
U
N
SCS ™ Panel
Power Supply
L1 (Hot)
L2 (Neutral)
Ground
From Breaker
Panel
Wire jumpers as
shown below for
either 120 or 240
volts AC.
120V use red jumpers, jump pos. 1&4, 2&3
240V use black jumper, jump pos. 2&4
HOT 120V NEUT 240V NEUT GND
1 2 3 4 5 6
240 Volts 120 Volts
120V use red jumpers, jump pos. 1&4, 2&3
240V use black jumper, jump pos. 2&4
HOT 120V NEUT 240V NEUT GND
1 2 3 4 5 6
