Part No. 4801-5117 Rev. 8-01 Farm Hand SCS 15
17.4 Setting the Local Network Address
DIP Switch Settings SCS™ Stage
Address
Assignment
No. 1 No. 2 No. 3
ON ON ON 1 -16
OFF ON ON 17-32
ON OFF ON 33-48
OFF OFF ON 49-64
ON ON OFF 65-80
OFF ON OFF 81-96
ON OFF OFF 97-112
OFF OFF OFF 113-128
LOCAL NET ADDRESS
SWX 1
ON
1 2 3
Inset A
Inset A
NOTE: If using the SCS Panel with the Vent Master 24, refer to the Vent
Master 24 Owners Manual (Part # 4801-5124) for proper wiring
connections and network address settings.
