82 Brocade 6910 Ethernet Access Switch MIB Reference
53-1002652-02
14
IronWare traps
Traps for RMON events
Brocade supports for the following traps for RMON from RFC 2819.
IronWare traps
This section presents the IronWare traps supported on devices running IronWare software.
NOTE
The Traps in the IronWare MIBs include the following lines in their description:
--#TYPE "Brocade Trap: Power Supply Failure"
--#SUMMARY "Power supply fails, error status %d."
--#ARGUMENTS { 0 }
--#SEVERITY MINOR
--#STATE OPERATIONAL
These lines are used by the HP OpenView network management system.
General traps
The table below lists the general traps generated by devices. Refer to the previous sections in this
chapter to determine if traps for a feature need to be enabled.
Trap Name and Number Varbind Description
risingAlarm
1.3.6.1.2.1.16.0.1 alarmIndex,
alarmVariable,
alarmSampleType,
alarmValue,
alarmRisingThreshold The SNMP trap that is generated when an alarm entry
crosses its rising threshold and generates an event that is
configured for sending SNMP traps.
fallingAlarm
1.3.6.1.2.1.16.0.2 alarmIndex,
alarmVariable,
alarmSampleType,
alarmValue,
alarmFallingThreshold The SNMP trap that is generated when an alarm entry
crosses its falling threshold and generates an event that is
configured for sending SNMP traps.
Trap Name and Number Varbind Severity Description
snTrapUserLogin
brcdIp.0.75 snAgGblTrapMessage Informational The SNMP trap that is generated
when a user logs in to a device.
Sample Trap Message:
Security: telnet login
from src IP 10.37.21.63 to
USER EXEC mode.
snTrapUserLogout
brcdIp.0.76 snAgGblTrapMessage Informational The SNMP trap that is generated
when a user logs out of a device.
Sample Trap Message:
Security: telnet logout
from src IP 10.37.21.63
from USER EXEC mode.
