Brocade VDX 8770-8 QuickStart Guide

9 of 34

Publication Number: 53-1002555-01

Items included with the Brocade VDX 8770-8

The Brocade VDX 8770-8 ships with the following items:

Brocade VDX 8770-8 chassis, populated with: (management modules, switch fabric modules, and line cards are
all packaged separately)

-

Management modules (one)

-

Switch fabric modules (up to six)

-

Line cards (up to eight)

-

Filler panels for unoccupied slots for all modules

-

Power supplies (up to eight)

-

Power supply filler panels for unoccupied bays

-

Fan assemblies (four)

Accessory kit containing the following items:

-

Console cable (RS-232 serial cable: The RS-232 cable has an adapter at one end that can be removed to
provide an RJ-45-style connector.)

-

Wrist strap (ESD grounding strap)

-

Ground lug kit

-

SFP extraction tool kit

-

China RoHS guide

-

Cable management comb

-

Brocade-branded USB device

-

Power cord retainer kit

-

Brocade VDX 8770-8 QuickStart Guide (this publication)

-

Hardware for securing the switch in a rack

-

Web pointer document

-

Air filter

The rack mount kits must be ordered separately.

Order the Brocade-branded transceivers (SFP, SFP+, or QSFP) and cables or direct-attach cables from your Brocade
distributor. The Brocade VDX 8770-8 supports SR and LR SFP and SFP+ transceivers. The QSFP transceivers are SR
transceivers only.

NOTE

For information about the transceivers that are qualified for the Brocade VDX 8770-8, refer to

http://www.brocade.com/downloads/documents/matrices/Brocade_Compatibility_Matrix.pdf

.
