Brocade VDX 8770-8 QuickStart Guide
11 of 34
Publication Number: 53-1002555-01
•
Either access to an FTP server or a Brocade USB device for backing up the switch configuration or collecting
supportsave output data (optional)
•
Transceivers (copper and optical) and compatible cables and direct-attach cables if needed
5. Ensure that the air intake and exhaust vents have a minimum of 5.1 cm (2 in.) of airspace.
6. Ensure that the air temperature on the air intake side is less than 40°C (104°F) during operation.
Power specifications
Power for the Brocade VDX 8770-8 can be supplied with either AC- or DC-based 3000 watt power supplies. The
Brocade VDX 8770-8 has room for up to eight power supplies.
shows the basic power specifications for each power supply.
.
CAUTION
For the DC input circuit to the system of a Brocade VDX 8770-8 (3000W power supply), make sure there
is an 80 Amp circuit breaker, minimum -48 VDC, double pole, on the input lugs to the power supply. The
input wiring for the connection to the switch should be copper wire, 2 American Wire Guage (AWG),
marked VW-1, and rated minimum 90°C.
The power requirements for a given switch configuration depend on which modules have been installed in the
switch.
shows the power consumption for the modules that can be used in the Brocade VDX 8770-8 switch
along with the power consumption for the cooling fans.
All numbers for the line cards assume that the card is fully populated with optical transceivers, including QSFPs for
the 12x40 GbE line cards. All ports are Ethernet.
TABLE 2
Power specifications
Specification
Value for 3000W AC power supply
Value for 3000W DC power supply
Input rating
16A
70A
Input voltage
200–240 VAC, 50-60 Hz, 16.0 Amp
maximum
-48 VDC
Operating range
180 ot 264 VAC
-40 to -60 VDC
Inrush current
Limited to 60 Amp peak for any initial
current surge or spike of 10 ms or less at
either cold or warm start. Any additional
inrush current surges or spikes in the form
of AC cycles or multiple AC cycles greater
than 10 ms and less than 150 ms, must not
exceed 25 Amp peak.
Limited to 70 Amp peak for any initial
current surge or spike of 10 ms or less at
either cold or warm start.
Output
12 VDC, 245 Amps
12 VDC, 245 Amps
