Brocade VDX 8770-8 QuickStart Guide

13 of 34

Publication Number: 53-1002555-01

NOTE

The 0

°

to 40

°

C (32

°

to 104

°

F) range applies to the ambient air temperature at the air intake vents on the port side

of the Brocade VDX 8770-8.

The temperature inside the Brocade VDX 8770-8 can be up to 90° C (194

°

F) for some modules during operation.

Cooling policy is based on a combination of ambient temperature and measured temperature on the modules.
Various combinations will result in an increase in fan speed to create more cooling in the switch.
If a component approaches a critical temperature that will trigger a module shutdown, there will be a WARNING
message in the raslog, followed by a CRITICAL message saying that the module will shut down in two minutes.
Use the show environment command to view temperature status.

Chassis slots

Switch slots are coded and numbered to differentiate between management module slots, switch fabric module
slots, and line card slots. Management modules (MM) must be installed only in slots M1 and M2. Switch fabric
modules (SFM) must be installed only in slots S1 through S6. There must be at least one SFM installed in either slot
S3 or slot S4. The line card slots, L1 through L8, can be filled with either 48x1G, 48x10G, or 12x40G line cards.
Unused slots must be filled with the correct filler panels to maintain adequate cooling.

Unpacking and installing the Brocade VDX 8770-8

Use the following procedure to unpack and install your Brocade VDX 8770-8.

CAUTION
Use safe lifting practices when moving the product. (C015)

NOTE

A fully populated Brocade VDX 8770-8 weighs approximately 165.56 kg (365 lb) and requires a hydraulic or assisted
lift to install it.

1. Unpack the Brocade VDX 8770-8.

a. Cut the bands that encircle the packaging.

b. Slide the upper portion of the cardboard shipping box up off the pallet and shipping tray.

Shock

20G, 6 ms duration, half-sine wave

33G, 11 ms duration, half-sine wave

Vibration

0.5G p-p, 5-500 Hz at 1.0 octave/minute

2.0G p-p, 5-500 Hz at 1.0 octave/minute

Airflow

Maximum: 1250 cu ft/min. (2124 cu
m/hr)
Nominal: 325 cu ft/min. (552 cu m/hr

None required

Maximum heat
dissipation

Up to 11500W or 39,250 BTU/hr

Not applicable

TABLE 4

Environmental requirements (Continued)

Condition

Acceptable range during operation

Acceptable range during non-operation
