Brocade VDX 8770-8 QuickStart Guide
Publication Number: 53-1002555-01
Brocade VDX 8770-8, nonport side
displays a sample configuration of the nonport side view of the Brocade VDX 8770-8.
FIGURE 2
Nonport side of the Brocade VDX 8770-8 (sample configuration)
1
Fan assemblies 1 and 2 (left to right)
3
Power supply exhaust vent
2
Fan assemblies 3 and 4 (left to right)
4
Ground lug
