IM DA100-11E 6-9
Commands
6
E0Cr+Lf: The processing of a received
command has completed normally.
E1Cr+Lf: There is an error in the received
command.
• After executing the command, the clock is
initialized to 96/01/01, 00:00:00.
XT Sets the temperature unit
Mode Setup mode
Setting XTp1
p1 Temperature unit
C
°
C
F
°
F
Example Set temperature unit to
°
C
XTC
XZ Performs A/D calibration of the input
module.
Mode A/D calibration mode
Calibration using the actual input
value at the input terminal
Setting XZp1, p2, p3, p4
p1 Subunit number (0 to 5)
p2 Slot number (0 to 5)
p3 CAL/EXEC
p4 Calibration item
• For universal input module
20 mV, 60 mV, 200 mV, 2 V, 6 V, 20
V, 50 V, Pt:1 mA, Pt:2 mA, Pt:1 mA-
H, Pt:2 mA-H, Cu:2 mA
• For mA input module
20 mA
• For strain input module
2k_ZERO, 2k_SPAN, 20k_ZERO,
20k_SPAN, 200k_ZERO, 200k_SPAN
• For digital input module
60 mV, 6 V
Example Execute a 20-mV range calibration on the module
in slot 1 of subunit 0.
XZ0, 1, CAL/EXEC, 20mV
Correcting the calibration value
manually (universal input module)
Setting XZp1, p2.....p5
p1 Unit number (0 to 5)
p2 Slot number (0 to 5)
p3 DISPLAY
p4 Zero calibration value for 20-mV range
p5 Span calibration value for 20-mV range
p6 Zero calibration value for 60-mV range
p7 Span calibration value for 60-mV range
p8 Zero calibration value for 200-mV range
p9 Span calibration value for 200-mV range
p10 Zero calibration value for 2-V range
p11 Span calibration value for 2-V range
p12 Zero calibration value for 6-V range
p13 Span calibration value for 6-V range
p14 Zero calibration value for 20-V range
p15 Span calibration value for 20-V range
p16 Zero calibration value for 50-V range
p17 Span calibration value for 50-V range
p18 Zero calibration value for Pt:1 mA
p19 Span calibration value for Pt:1 mA
p20 Zero calibration value for Pt:2 mA
p21 Span calibration value for Pt:2 mA
p22 Span calibration value for Pt:1 mA-H
p23 Span calibration value for Pt:2 mA-H
p24 Zero calibration value for Cu:2 mA
p25 Span calibration value for Cu:2 mA
Correcting the calibration value
manually (DCV/TC/DI input module)
Setting XZp1, p2.....p17
p1 Unit number (0 to 5)
p2 Slot number (0 to 5)
p3 DISPLAY
p4 Zero calibration value for 20-mV range
p5 Span calibration value for 20-mV range
p6 Zero calibration value for 60-mV range
p7 Span calibration value for 60-mV range
p8 Zero calibration value for 200-mV range
p9 Span calibration value for 200-mV range
p10 Zero calibration value for 2-V range
p11 Span calibration value for 2-V range
p12 Zero calibration value for 6-V range
p13 Span calibration value for 6-V range
p14 Zero calibration value for 20-V range
p15 Span calibration value for 20-V range
p16 Zero calibration value for 50-V range
p17 Span calibration value for 50-V range
Correcting the calibration value
manually (mA input module)
Setting XZp1, p2, p3, p4, p5
p1 Unit number (0 to 5)
p2 Slot number (0 to 5)
p3 DISPLAY
p4 Zero calibration value for 20-mA range
p5 Span calibration value for 20-mA range
Correcting the calibration value
manually (Strain input module)
Setting XZp1, p2, p3, ....., p9
p1 Unit number (0 to 5)
p2 Slot number (0 to 5)
p3 DISPLAY
p4 Zero calibration value for 2k range
p5 Span calibration value for 2k range
p6 Zero calibration value for 20k range
p7 Span calibration value for 20k range
p8 Zero calibration value for 200k range
p9 Span calibration value for 200k range
Correcting the calibration value
manually (Digital input module)
Setting XZp1, p2.....p7
p1 Unit number (0 to 5)
p2 Slot number (0 to 5)
p3 DISPLAY
p4 Zero calibration value for 60-mV range
p5 Span calibration value for 60-mV range
p6 Zero calibration value for 6-V range
p7 Span calibration value for 6-V range
Example Modify the span calibration value for the 6V range
of the module in slot 1 of subunit 0 to 32000.
XZ0, 1, DISPLAY, , , , 32000
Storage of A/D calibration data in a
module (A/D calibration END
processing)
Setting XZp1, p2, p3, p4
p1 Unit number (0 to 5)
p2 Slot number (0 to 5)
p3 END
6.1 Setting Command
