< 4. OPERATION >
4-1
IM 12T03A01-02E
4. OPERATION
4.1
Component Names and Function
4.1.1 Density
Detector
Vibrator assembly
Cover
Terminal box cover
Terminal box
Case
Capacitance
pickup electrode
Oscillation
amplifier
Coupler
Piezoelectric
element
Lock-screw
(Keep loose during detector operation)
Lock
Vibrators
Figure 4.1
Density Detector
