IM 12A00A01-61E
Foundation Fieldbus 3-11 3-11
Table 3.5 VCR Static Entry
Sub-
index
Parameter Description
1 FasArTypeAndRole Indicates the type and role of
communication (VCR). The
following 3 types are used for
EXA.
0x32: Server (Responds to
requests from host.)
0x44: Source (Transmits alarm
or trend.)
0x66: Publisher (Sends AI
block output to other
blocks.)
2 FasDllLocalAddr Sets the local address to
specify VCR in EXA. A range of
0x20 to 0xF7 in hexadecimal.
3 FasDllConfigured
RemoteAddr Sets the node address of the
called party for communication
and the address (DLSAP or
DLCEP) used to specify VCR
in that address. For DLSAP
or DLCEP, a range of 0x20 to
0xF7 in hexadecimal is used.
Addresses in Subindex 2 and
3 need to be set to the same
contents of the VCR as the
called party (local and remote
are reversed).
4 FasDllSDAP Specifies the quality of
communication. Usually, one of
the following types is set.
0x2B: Server
0x01: Source (Alert)
0x03: Source (Trend)
0x91: Publisher
5 FasDllMaxConfirm
DelayOnConnect To establish connection for
communication, a maximum
wait time for the called party’s
response is set in ms. Typical
value is 60 seconds (60000).
6 FasDllMaxConfirm
DelayOnData For request of data, a
maximum wait time for the
called party’s response is
set in ms. Typical value is 60
seconds (60000).
7 FasDllMaxDlsduSize Specifies maximum DL Service
Data unit Size (DLSDU).
Set 256 for Server and Trend
VCR, and 64 for other VCRs.
8 FasDllResidual
ActivitySupported Specifies whether connection is
monitored. Set TRUE (0xff) for
Server. This parameter is not
used for other communication.
9 FasDllTimeliness
Class Not used.
Sub-
index
Parameter Description
10 FasDllPublisherTime
WindowSize Not used.
11 FasDllPublisher
SynchronizaingDlcep Not used.
12 FasDllSubsriberTime
WindowSize Not used.
13 FasDllSubscriber
SynchronizationDlcep Not used.
14 FmsVfdId Sets VFD for EXA to be used.
0x1: System/network
management VFD
0x1234: Function block VFD
15 FmsMaxOutstanding
ServiceCalling Set 0 to Server. It is not
used for other applications.
16 FmsMaxOutstanding
ServiceCalled Set 1 to Server. It is not
used for other applications.
17 FmsFeatures
Supported Indicates the type of
services in the application
layer. In the EXA, it is
automatically set according
specific applications.
33 VCRs are factory-set as shown in the table 3.6.
