IM 1E10C1-E 8-3
8. ACTUAL OPERATON
8.1.3 Zero Adjustment Using HART Communicator
1. Device setup 2. Diag/Service 1. Test device 3. Zero tuning
ADMAG SE :
Zero tuning
Enable
Inhibit
Enable
DEL DEL ESC ENTER
Select “Enable” and press ENTER (F4) and SEND (F2).
Press OK (F4).
Wait for about 20 seconds.
Press OK (F4).
This parameter is only for execution.
Call up “Zero tuning” display.
1. Test device 2. Auto zero
ADMAG SE :
About to enter auto
zero
DEL DEL ABORT OK
1
F4
2
ADMAG SE :
Auto zero passed
HELP SEND ABORT OK
3
(OK)
F2
(SEND)
F4
(ENTER)
F4
(OK)
Call up “Auto zero” display.
ADMAG SE :
waiting for auto zero
to complete
DEL DEL ABORT ENTER
1. Zero adjustment should be done only when the fluid velocity is completely zero by
closing the valve.
2. Do not turn off the power to the ADMAG SE immediately after zero adjustment.
Powering off within 20 seconds after zero adjustment will return adjustment to the
previous setting.
IMPORTANT
