Wa t l o w S e r i e s S D 6 P I D w i t h D e v i c e N e t ■ 2 8 ■
Table 35. Profiling Class Attributes
Attribute # Access
Rule Name DeviceNet
Data Type Description of Attribute Semantics of Values
1 Get Revision UINT Revision of this object The revision level of this
object (currently 1)
2 Get Max Instance UINT Max allowed Instances of this
object Always 1 for this Class
Class Services:
• 0x0E GET ATTRIBUTE SINGLE
Instance Services:
• 0x0E GET ATTRIBUTE SINGLE
• 0x10 SET ATTRIBUTE SINGLE
NOTE: All successful Explicit Message
Responses from a SET service will contain no
data. The response will be a two-byte message
containing the requester’s MAC ID and Service
Code (with R/R bit set).
Profiling Object
Class Code: 69hex
Profiling Object
The Profiling Object provides access to parameters that
contain profiling parameters.
Table 34. Profiling Object Revision History
Revision Description
01 Initial Release
Attribute # Access Rule Name DeviceNet
Data Type Description of Attribute Semantics of Values
115 Get/set P16 USINT Programmable Parameter
Location 16 See Programming Page
in user’s manual.
116 Get/set P17 USINT Programmable Parameter
Location 17 See Programming Page
in user’s manual.
117 Get/set P18 USINT Programmable Parameter
Location 18 See Programming Page
in user’s manual.
118 Get/set P19 USINT Programmable Parameter
Location 19 See Programming Page
in user’s manual.
119 Get/set P20 USINT Programmable Parameter
Location 20 See Programming Page
in user’s manual.
120 Get/set P21 USINT Programmable Parameter
Location 21 See Programming Page
in user’s manual.
121 Get/set P22 USINT Programmable Parameter
Location 22 See Programming Page
in user’s manual.
122 Get/set P23 USINT Programmable Parameter
Location 23 See Programming Page
in user’s manual.
