PL3000 Series Hardware Manual
4-26
4.6.2
Dimensions of the 4 slot Unit (Installation fasteners attached)
Unit: mm [in.]
460 [18.11]
419 [16.5]
441 [17.36]
39
0 [1
5.35]
234 [9.21]
2 [0.08]
13
[0.51]
35
2 [1
3.86]
2
32 [9.1
3]
Front
Side
Top
360 [14.17]
2.5 [0.10]
DISPLAY AREA
CENTER
16 [0
.6
3]
37
4 [14
.7
2
]
