Chapter 1 Overview
1-5
1.3 Power Supply
The PL has three kinds of power supply states: Non-energized, Normal State, and Soft OFF State
*1
.
Each state is outlined in the following diagram:
*1 The Soft OFF refers to the state when Windows
®
has been shut down and the power is provided only for
the electric circuit to boot system. This Soft OFF State is different from Windows
®
System Standby.
*2 Only when the panel computer is used.
*3
„
RAS Interfaces (page 3-13)
*4 The function that activates the PL unit via LAN. PL3000 Series Reference Manual
• Whenever you turn the PL unit’s power OFF, wait until the internal HDD stops
spinning (approximately 5 seconds) before turning the power ON again.
SEE
SEE
Power State: Non-energized Normal States Soft OFF
Power LED: OFF Green Lighting Green Blinking
PL’s
power On
For
Normal
State
PL’s system
activated Shut down by
Windows program System
Stop Reset Switch
ON
Power Switch OFF,
Remove Power
Cable For
Non-energized
State
Reset signal
input from RAS
port
*3
WAKE input from
LAN controller
(WOL function)
*4
Screen of PL
*2
:OFF ON OFF
