Chapter 4 Dimensions
4-17
4.4
PL-3700T Series
4.4.1
Dimensions of the 2 slot Unit (Installation fasteners attached)
Unit: mm [in.]
404 [15.91]
356 [14.02]
8 [0.31]
383 [15.08]
425 [16.73]
325
[12
.8]
2
82 [1
1.1]
304
[1
1
.97
]
166 [6.54]
10 [0.39]
2 [0.08]
Top
Front
Side
