12. General Specifications
12.1 Electrical Specifications
12.2 Environmental Specifications
Pow
e
r Supply
Rated Voltage
DC5V (Supplied from LT)
Power Consumption
2.4W max.
Voltage Endurance
AC500V 20mA for 1 minute
(between charging and FG terminals)
Insulation Resistance
DC500V 10M
Ω (min.)
(between charging and FG terminals)
Phy
s
ic
al
Surrounding Air
Temperature
0°C to 50°C
Storage
Temperature
-20°C to + 60°C
Ambient Humidity
10% RH to 90% RH
(Wet bulb temperature: 39°C max. - no condensation.)
Storage Humidity
10% RH to 90% RH
(Wet bulb temperature: 39°C max. - no condensation.)
Dust
0.1mg/m
3
or less
(non-conductive levels)
Pollution Degree
For use in Pollution Degree 2 environment
Atmosphere
Free of corrosive gas
Air Pressure Vibration
Resistance (availment
altitude)
800 to 1114hPa
(2000m above sea-level max.)
Mec
hanical
Vibration Resistance
Compliant with JIS B 3502, IEC61131-2
5 to 9Hz single-amplitude 3.5mm [0.14in.]
9 to 150Hz constant-accelerated velocity 9.8m/s
2
X,Y,Z directions for 10 cycles (100 minutes)
Impact Resistance
Compliant with JIS B 3502, IEC61131-2
(147m/s
2
to three times each X, Y, Z direction)
Elec
tric
al
Noise Immunity
(via noise simulator)
Noise Voltage: 1000 V
P-P
Pulse Duration: 1µs
Rise Time:
1ns
Electrostatic
Discharge Immunity
Contact Electrical Discharge
6kV (complies with IEC61000-4-2 Level 3)
