AFL-F08A-N270 Panel PC
Page 83
5.7.2 Southbridge Configuration
The Southbridge Configuration menu the Southbridge chipset to be configured.
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Exit
Southbridge Configuration
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
Audio Controller
[Auto]
ÅÆ Select
Screen
↑ ↓ Select
Item
Enter Go to SubScreen
F1 General
Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 24:Southbridge Chipset Configuration
Î Audio Controller [Auto]
Use the Audio Controller option to enable or disable the onboard audio.
Î
Auto D EFAULT
The audio chip is activated if detected
Î
Azalia High Definition capabilities enabled
Î
AC'97 only
Only AC'97 audio capabilities enabled
Î
Disabled The audio chip is disabled
5.8 Exit
Use the Exit menu to load default BIOS values, optimal failsafe values and to save
configuration changes.
