IEI Integration AFL-F08A v2.10 - Manual (Page 74)

AFL-F08A-N270 Panel PC
Page 62
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Exit
ACPI Settings
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
Suspend mode
[S1 (POS)]
ÅÆ Select
Screen
↑ ↓ Select
Item
Enter Go to SubScreen
F1 General
Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 9: General ACPI Configuration
Î Suspend Mode [S1(POS)]
Use the Suspend Mode option to specify the sleep state the system enters when it is not
being used.
Î
S1 (POS) D EFAULT
System appears off. The CPU is stopped. RAM is
refreshed.
Î
S3 (STR) System appears off. The CPU has no power. RAM in slow
refresh. Power supply in reduced power mode.
5.3.5.2 APM Configuration
The APM Configuration menu allows the advanced power management options to be
configured.
