AFL-F08A-N270 Panel PC
Page 60
ƒ RS232 D EFAULT
ƒ RS422/RS485
Î Serial Port 4 Address [2E8]
Sets the port address of serial port 4.
ƒ Disabled
ƒ 2E8 D EFAULT
Î Serial Port 4 IRQ [IRQ3]
Sets the interrupt address of serial port 4.
ƒ 10 D EFAULT
5.3.4 Hardware Health Configuration
The Hardware Health Configuration menu shows the operating temperature, fan speeds
and system voltages.
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Exit
Hardware Health Event Monitoring
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
CPU Temperature
:55ºC/133ºF
System Temperature :53ºC/127F
CPU Core
:1.184 V
+1.05V :1.056 V
+3.30V :3.290 V
+5.00V :4.972 V
+12.0V :12.097V
+1.50V :1.472
V
+1.80V :1.792 V
5VSB :4.999 V
VBAT :3.264 V
ÅÆ Select
Screen
↑ ↓ Select
Item
Enter Go to SubScreen
F1 General
Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 7: Hardware Health Configuration
5.3.5 Power Configuration
The Power Configuration menu configures the power related settings.
