AFL-F08A-N270 Panel PC
Page 70
Î
Auto D EFAULT
BIOS auto-detects the current USB.
Î
Floppy The USB device will be emulated as a floppy drive.
The device can be either A: or B: responding to
INT13h calls that return DL = 0 or DL = 1
respectively.
Î
Forced FDD
Allows a hard disk image to be connected as a
floppy image. This option works only for drives
formatted with FAT12, FAT16 or FAT32.
Î
Hard Disk Allows the USB device to be emulated as hard disk
responding to INT13h calls that return DL values of
80h or above.
Î
CDROM
Assumes the CD-ROM is formatted as bootable
media. All the devices that support block sizes
greater than 512 bytes can only be booted using this
option.
5.4 PCI/PnP
Use the PCI/PnP menu (
548H548H
BIOS Menu 14 ) to configure advanced PCI and PnP settings.
WARNING!
Setting wrong values for the BIOS selections in the PCIPnP BIOS
menu may cause the system to malfunction.
