AFL-F08A-N270 Panel PC
Page 47
5.1 Introduction
The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to
certain system settings. This chapter outlines the options that can be changed.
5.1.1 Starting Setup
The AMI BIOS is activated when the computer is turned on. The setup program can be
activated in one of two ways.
1. Press the D ELETE
key as soon as the system is turned on or
2. Press the D ELETE
key when the “Press Del to enter SETUP” message
appears on the screen. 0.
If the message disappears before the D
ELETE
key is pressed, restart the computer and try
again.
5.1.2 Using Setup
Use the arrow keys to highlight items, press E
NTER
to select, use the PageUp and
PageDown keys to change entries, press F1 for help and press E
SC
to quit. Navigation
keys are shown in.
Key Function
Left arrow Move to main menu to the left
Right arrow Move to main menu to the right
Up arrow Move item selection up
Down arrow Move item selection down
Esc key At top level menu: Exit BIOS without saving changes
At submenu level: Go back up one menu level
+/- Change value of current selection
F1 key General help, only for Status Page Setup Menu and Option
Page Setup Menu
F2 /F3 key Change color from total three colors. F2 to select color
forward.
