IEI Integration AFL-F08A v2.10 User Manual

Page 113

AFL-F08A-N270 Panel PC

Page 101

Figure B-14: Select a Local Source Drive

Step 6:

Select a source partition (Part 1) from basic drive as shown in

780H780H637H637H

Figure B-15

Then click OK.

Figure B-15: Select a Source Partition from Basic Drive

Step 7:

Select 1.2: [Recovery] NTFS drive and enter a file name called

iei

(

781H781H638H638H

Figure B-16

). Click Save. The factory default image will then be saved in the

selected recovery drive and named IEI.GHO.

WARNING:

The file name of the factory default image must be

iei.GHO
