AFL-F08A-N270 Panel PC
Page 6
Specification Description
SSD CF Type II slot
Watchdog Timer Software Programmable supports 1 sec. ~ 255 sec. system reset
Audio AMP 1.5 W + AMP 1.5 W (built-in stereo speakers)
Camera 300 K pixel webcam
Expansion 1 x PCIe mini card (wireless LAN 802.11 b/g/n module)
1 x Bluetooth module (USB interface, Bluetooth v 2.0)
Construction Material ABS + PC plastic front frame
Mounting Panel, Wall, Stand, Arm (VESA 75 mm x 75 mm)
Dimensions (W x H x D) 234 mm x 177 mm x 43 mm
Operation Temperature -10ºC ~ 50ºC
Storage Temperature -20ºC ~ 60ºC
Net weight 1.8 kg
IP level (front panel) IP 64
EMC CE, FCC and CCC
Safety CB
Touch Screen AFL-F08A-N270/R: 5-wire analog resistive type touch window
AFL-F08A-N270/PC: Multi-touch projected capacitive touch screen (USB)
Power Adapter 36 W power adapter
Input: 100 V AC ~ 240 V AC @ 50 Hz / 60 Hz
Output: 12 V DC
Power Consumption 32 W
I/O Ports and Switches 1 x 12 V DC input jack
1 x Audio connector
1 x RS-232 COM port connectors
1 x RS-232/422/485 COM port connector
2 x RJ-45 for GbE LAN
2 x USB 2.0 ports
1 x External SATA connector
1 x Power switch
1 x Reset button
Table 1-1: AFL-F08A-N270 System Specifications
