AFL-F08A-N270 Panel PC
Page 20
3.7.2 Preconfigured Jumpers
WARNING:
Do not change the settings on the jumpers in described here. Doing so
may disable or damage the system.
The following jumpers are preconfigured for the AFL-F08A-N270. Users should no change
these jumpers (
511H511H
Table 3-2 ).
Jumper Name Label Type
LVDS voltage selection J_VLVDS1 3-pin header
Touch Screen Select J1 4-pin header
Panel Type and Resolution J_LCD_TYPE1 10-pin header
Table 3-2: Preconfigured Jumpers
3.7.3 AT/ATX Power Select Jumper Settings
Jumper Label: Switch
Jumper Type: Two-setting switch
Jumper Location: See
512H512H
Figure 3-7
Set this switch to the required power setting.
