PPC-5xxx-9455 Panel PC
Page 66
Step 5: Once the panel PC with the attached rack/cabinet bracket has been properly
inserted into the rack or cabinet, secure the front of the rack/cabinet bracket to
the front of the rack or cabinet (Figure 4-25).
4.7.4 Arm Mounting
The PPC-5xxx-9455 is VESA (Video Electronics Standards Association) compliant and
can be mounted on an arm with a 100 mm interface pad. To mount the PPC-5xxx-9455 on
an arm, please follow the steps below.
Step 1: The arm is a separately purchased item. Please correctly mount the arm onto
the surface it uses as a base. To do this, refer to the installation documentation
that came with the mounting arm.
NOTE:
When purchasing the arm please ensure that it is VESA compliant and
that the arm has a 100 mm interface pad. If the mounting arm is not
VESA compliant, it cannot be used to support the PPC-5xxx-9455 flat
panel PC.
Step 2: Once the mounting arm has been firmly attached to its surface, lift the
PPC-5xxx-9455 flat panel PC onto the interface pad of the mounting arm.
Step 3: Align the retention screw holes on the mounting arm interface with those in the
PPC-5xxx-9455 flat panel PC. The PPC-5xxx-9455 flat panel PC arm mount
retention screw holes are shown below.
